- Inputloutput side with surge absorbing circuit, which can effectively extend the life of the relay contact, and canslow the
- instantaneous impact current of load side.
- NPN/PNP bipolar input coresponding, and the indicator light will also follow the input signal of different and bright color ;
- Green - NPN .Red-the PNP.
- Input side wrong line protection.
Y430-O~Y435-O
Brand:SiRON
8536901100
Non-returnable
₹5,000.00
Product Details
Product Description
Suitable wire
Type selection reference
| Model | Y430-0 | Y431-0 | Y432-0 | Y433-0 | Y434-0 | Y435-0 |
| Name | 2-bit 1C power Relay module | 2-bit 2C power Relay module | 4-bit 1C power Relay module | 4-bit 2C power Relay module | 8-bit 1C power Relay module | 8-bit 2C power Relay module |
The relay module control signal can be set as an NPN and PNP, specific methods please consult sales .
Specifications
| Model | Y430-0 Y432-0 Y434-0 | Y431-0 Y433-0 Y435-0 | ||
Input | Relay Coil Specifications | |||
| (V)Nominal coil voitage | DC 24V | |||
| (MA)Nominal operating curent | 25.7mA(DC24V) | |||
| (Ω)Coi resistance | 1080Ω(DC24V) | |||
| (V)Pick-up Volitage | More than 80% (AC) and more than 70% (DC) of the rated voltage | |||
| Drop-out Voltage | More than 80% (AC) and more than 70% (DC) of the rated voltage | |||
| Max.alowable voitage | 140% of the rated voltage | |||
| (MW)Nomnal operatng powe | 900MW(AC),530MW(DC) | |||
Output | Contact | |||
contact Specification | Contact structure | 1C | 2C | |
| Contact Materilal | Silver-nickel | Au-flashed AgNi type | ||
| Contact reslstance | 100mΩBy (through the DC 6V1A voltage drop method) | Below 50mΩ (by the DC 6V 1A voltage drop method) | ||
| Rated control capacity | NO contact: 12A,NC contact: 12A(AC250V),6A(30V) | 5A 250VAC、5A30V DC | ||
| Rated control capacity | NO contact: 6A,NC contact:6A(AC250V),3A(30V) | |||
| Rated control capacity | NO contact: 3000V(AC),360W(DC); NC contact:3000V(AC),180W(DC) | |||
| maximum alowable voltage | AC250V,DC110V | |||
| maximum allowable voltage | DC100mA,DC5V | |||
| Electnical propertles | Action time | 15ms | ||
| Teset time | 10ms | |||
| Suroundings | Operating temperature | -40℃~70℃ | ||
| Use humidity | 5%～85% | |||
Life | Mechanical | 30 million times (on-off frequency 180 times per minute) | ||
| Electrial | More than 100,000 times | |||
The relay module control signal can be set as an NPN and PNP, specific methods please consult sales .
