PoE standard:Complies with IEEE802.3af/IEEE802.3at; Maximum single port:15.4W(IEEE 802.3af);Maximum single port:30W(IEEE 802.3at);
PoE compatibility :IEEE 802.3af/at adaptive
PoE port output voltage:DC48-52V;
PoE power supply core:1/2+,3/6-(af/at); 1/2/4/5+，3/6/7/8-(bt);
Access terminal
Phoneix
Mean time between failures
300,000 hour
Mechanical characerisfic
Shell
IP40 protection grade, metal outer shell
Install
DIN card rail type, wall-mounted installation
Heat dissipation mode
Naturally cold, without a fan
Working environment
Operafing temperature
-40~85℃(-40~185°F)
Storage temperature
-40~85℃(-40~185°F)
Relative humidity
5 % ~ 9 5 % ( No condensation )
LEDindex
Powerindicator light
PWR
Interface indicator
Electrical port, optical port ( L i n k / A C T )
System light
Status
Industry standard
EMI: FCC Part 15 Subpart B Class A,EN 55022 Class A EMS: IEC(EN)61000-4-2(ESD):±8kV(contact),±15kV(air) IEC(EN)61000-4-3(RS):10V/m(80~1000MHz) IEC(EN)61000-4-4(EFT):PowerPort:±4kV;Data Port:±2kV IEC(EN)61000-4-5(Surge):Power Port:±2kV/DM,±4kV/CM;Data Port:±2kV IEC61000-4-6(CS):10V(150kHz~80MHz)/IEC(EN)61000-4-16(CM EMI):30V cont.300V,1s IEC 60068-2-27(Shock)/IEC 60068-2-32(Freefall)/IEC 60068-2-6(Vibration)
Software parameter
Network topology
Ring topology
support
Star topology
support
Bus topology
support
Tree topology
support
Hybrid topology
support
POE support
PoE port
1-8
PoE Protocol
802.3af,802.3at
PinAssignment
12+36-
PoE Management
support
Layer3 Function
IPV4 management address
support
IPV6 management address
support
Static Routes lpv4
32 support
Staic Routes pv6
32 support
Address resolution protocol
support
Loopback interface
support
DHCP Server
support
DNS Server
support
Aggregation service
ACL
Supports MACstandard/extended ACLs Supports IPV4 standard/extended AC Supports IPV6 standard/extended AC
QOS
Support QOS re-marking;Support port trust; Support port peed limiting;Support speed limit for export queues; Support SPand WRR scheduling algorithms; Supports COS mapping,DSCPmapping and IPpriority mapping
Security
Management channel configuration
support
AAAcertification
support
802.1X authentication
support
MAC-Based authentication
support
WEB-Based authentication
support
DoS anti-attack
support
DynamicARP check
support
DHCP Snooping
support
IPSource Guard
support
Port security
support
Port isolation
support
Storm control
support
Equipment diagnosis
RAM log
support
Flash log
support
Port mironing
support 1:1 or 1:M
Ping
support
Traceroute
support
Electrical test
support
Optical module information
support
UDLDprotocol
support
Layer 2 Switching
Switching capacity
20Gbps
Packet forwarding rate
14.88 Mpps
MACaddress table
8K
Buffer
4.1M
Forwarding delay
<10μs
MD/MDIX
support
Number of wlans supported
256
GARPVLAN registration protocol
support
Protocol VLAN
support
Voice VLAN
support
Surveillance VLAN
support
MAC VLAN
support
Etherchannle/802.3ad
support
LACP
support
Interface Speed
support
Duplex Mode
support
Fow Control
support
Jumbo frame
support
DHCP Client
support
SNTP Client
support
Port Statistics
support
Protected Ports
support
EEE
support
Management
UserManagement
support
SystemLog
support
UpgradeFirmware
support
ConfiqurationFileDownload/Upload
support
SNMP
support SNMPV1/V2/V3
WEB management
support
CLI
support
Telnet/SSH
support
RMON
support
