Motion Control SiRON T382-12 Web-based Network Management 2 Optical 8 Power Industrial Switch
SiRON T382-12 Web-based Network Management 2 Optical 8 Power Industrial Switch
Provides 8 10/100/1000Mbps lower electrical ports to 2 1000Mbps SFP upper optical ports;
SC/LC/FC/ST/SFP optical interface optional, extensible IEEE802.3af(15.4W)/at(30w);
Support wide temperature design -40℃~85℃ to meet harsh environment application requirements;
Support dual power supply redundancy backup, anti-protection input power supply,
EMC industrial level 4 electromagnetic interference;
Support IP40 protection class, fanless design, aluminum alloy metal housing, DIN rail mounting/wall mounting
T382-12
Brand:SiRON
Code:8517621900
Product Details
Product Description
Selection reference
| model | T382-12 | T382-12AB | T382-12E | T382-12E-AB |
| Electrical interface | 8 |
| Opticalport | 2 |
| Speed | 1000M |
| Power source | DC12-52V | DC48-52V |
Port description | 8x10/100/1000Mbps
RJ45 port，
2x1000Mbps SFP Fiber | 8x10/100/1000Mbps
RJ45 port 2x1000Mbps
SC Fiber Interface(BIDI,20KM,
TX1310/RX1550nm) | 8x10/100/1000Mbps
RJ45 POE port，
2x1000Mbps SFP Fiber | 8x10/100/1000Mbps
RJ45 POE port，
2x1000Mbps
SC Fiber Interface(BIDI,20KM,
TX1310/RX1550nm) |
Specification
| Rj45 port | 10/100/1000BaseT (X)automatic detection;Full/half-duplex MDI/MDI-X adaptive |
| Network protocol | IEEE802.3-CSMA/CD;IEEE802.3i-10Base-T;
IEEE802.3u-100Base-TX/FX;IEEE802.3x-flow control; IEEE802.3z - 1000Base-X; IEEE802.3ab - 1000Base-T; |
| PoE(optional) | PoE standard:Complies with IEEE802.3af/IEEE802.3at;
Maximum single port:15.4W(IEEE 802.3af);Maximum single port:30W(IEEE 802.3at);
PoE compatibility :IEEE 802.3af/at adaptive PoE port output voltage:DC48-52V; PoE power supply core:1/2+,3/6-(af/at); 1/2/4/5+，3/6/7/8-(bt); |
|
| Access terminal | Phoneix |
| Mean time between failures | 300,000 hour |
Mechanical
characerisfic |
Shell | I P 4 0 protection grade, metal outer shell |
Install | D I N card rail type, wall-mounted installation
|
Heat dissipation mode | Naturally cold, without a fan |
Working
environment |
Operafing temperature | -40~85℃(-40~185°F) |
Storage temperature | -40~85℃(-40~185°F) |
Relative humidity | 5 % ~ 9 5 % ( No condensation ) |
LEDindex |
Powerindicator light | PWR |
Interface indicator | Electrical port, optical port ( L i n k / A C T ) |
System light | Status |
| Industry standard | EMI:
FCC Part 15 Subpart B Class A,EN 55022 Class A
EMS:
IEC(EN)61000-4-2(ESD):±8kV(contact),±15kV(air)
IEC(EN)61000-4-3(RS):10V/m(80~1000MHz)
IEC(EN)61000-4-4(EFT):PowerPort:±4kV;Data Port:±2kV
IEC(EN)61000-4-5(Surge):Power Port:±2kV/DM,±4kV/CM;Data Port:±2kV
IEC61000-4-6(CS):10V(150kHz~80MHz)/IEC(EN)61000-4-16(CM EMI):30V cont.300V,1s
IEC 60068-2-27(Shock)/IEC 60068-2-32(Freefall)/IEC 60068-2-6(Vibration) |
Software paramater
| Network topology | Ring topology | support |
| Star topology | support |
| Bus topology | support |
| Tree topology | support |
| Hybrid topology | support |
| POE support | PoE Management | support |
| Layer 2 Switching | Switching capacity | 20Gbps |
| Packetforwarding rate | 14.88 Mpps |
| MAC address table | 4K |
| Buffer | 12KBytes |
| Forwarding delay | <10μs |
| MDI/MDIX | support |
| Number of vlans supported | 32 |
| Ethernet channel | Only supports static. |
| Interface Speed | support |
| Duplex Mode | support |
| Fow Control | support 9K bytes |
| Jumbo frame | support |
| DHCP Client | support |
| Port Statistics | support一 |
| EEE | support |
| Loopcheckloop prevention | support |
| STP/RSTP | support |
| STPPort Fast | support |
| IGMP Snooping | support |
| Factory data reset | support |
| Remote restart device | Support port speed limiting |
| Aggregation service | Qos | Support speed limit support for export queues |
| support |
| Management | UserManagement | support |
| UpgradeFirmware | support |
| ConfiqurationFileDownload/Upload | support |
| WEB management | support |
| Security | Protected Ports | support |
| Storm control | support |
| Equipment diagnosis | Portmirroring | support 1:1 |
