SiRON T381-3-PN Unmanaged 8 ports Profinet protocol High-precision Industrial Switch

SiRON T381-3-PN Unmanaged 8 ports Profinet protocol High-precision Industrial Switch

Name: SiRON T381-3-PN Unmanaged 8 ports Profinet protocol High-precision Industrial Switch
Brand: SIRON
Price: 5000.0 INR
Availability: InStock

Provide 8 10/100Mbps electrical ports, support Profinet protocol priority transmission;

Support wide temperature design -40℃~75℃ to meet harsh environment application requirements;
Support anti-reverse connection, support built-in overcurrent 3.0A protection;
Support storm suppression, flow control, one-click VLAN, loop detection and other functions, fanless, low power design;
Support IP40 protection rating, metal housing DIN rail mounted or wall mounted

Model:T381-3-PN

Brand:SiRON

Code:8517621900

Non-returnable

₹5,000.00

Product Details

Product Description

Selection reference

Model	T381-3-PN
Electrical interface	8
Speed	100M
Power source	12~48VDC or 24VAC
Port description	8x10/100Mbps RJ45 port

Specification

Rj45 port			10/100 BASE-T(X)adaptive RJ45,full-duplex/half-duplex mode adaptive, MDI/MDI-Xautomatic detection
Standards and protocols			10Base-T,in accordance with IEEE802.3;100Base-TX,in compliance with IEEE 802.3 Flow control,in accordance with IEEE 802.3x;VLAN follows IEEE 802.1Q
Dip switch			1-loop detection、2-Storm suppression、3-VLAN、4-fluid control
Input terminal			adopts 4-digit 5.08mm pitch terminal blocks and supports reverse connection preventi
Switch properties	Transmission mode		store and forward
	Switching delay		<10μs
	MAC address		2K
	Backplane bandwidth		1.6G
	Power dissipation		Empty load:0.2W@12VDC;Full load:0.8W@12VDC
Machine structure	Shell		IP40 protection grade,metal casing
	Install		DIN rail mounting
Pilot lamp			Power indicator light,operation indicator light,interface indicator light
Operating temperature			-40~75℃
Storage temperature			-40~85℃
Relative humidity			5%~95%(no condensation)
Mean time between failures			300,000 hours
Industry standard		IEC61000-4-2(ESD,electrostatic discharge Immunity),Level 3 IEC61000-4-4(EFT,Electrical Fast Transient Pulse Immunity),Level3 IEC61000-4-5(Surge,wave impulse immunity),Level 3 Impact: IEC60068-2-27Free fall: IEC60068-2-32 Vibration: IEC60068-2-6
