Supports 16-channel 24V/0V power distribution output;
The module must be used in conjunction with the T330 series coupler.
The module must be used in conjunction with the T330 series coupler.
The expansion module cannot be used independently
T330-P
SiRON
8517623990
Non-returnable
Product Details
Product Description:
About selection:
Selection example: T330-P1 represents the blade-type I/O module series, with a
24V power distribution output module. Auxiliary features
| Code | Auxiliary |
| 1 | Power 24V Power Distribution Output Module |
| 2 | Power OV Power Distribution Output Module |
Specifications:
| Powerparameters | |
| Usysbus input power supply rated voltage | 5V DC+20%1-15%(4.25V DC~6V DC) |
| Usys bus input power supply rated curent | <60mA(Typical value at 5V Dc) |
| Recommended voltage | T300-P1:24V; T300-P2:0V |
| Module hot-swappable function | nonsupport |
| Connection parameters | |
| Connection technology | PUSH-INtype terminal block |
| Connection type | System/On-site power supply/input |
| Conductor crimping area | 26~16AWG/0.2~1.5mm² |
| Strip length | 10mm |
| Installation method | DIN-35 |
| Shell material | PC plastic |
| Environmental conditions | |
| Allowable ambient temperature(during operation) | -40~75℃ |
| Allowable ambient temperature (for storage) | -40~85℃ |
| Protection type | IP20 |
| Pollution grade | 2 |
| Operating altitude | 0~2000m |
| Relative humidity(without condensation) | 5~95%RH |
Auxiliary module parameters:
| Auxiliary module | T330-P1 | T330-P2 |
| Output type | 24V | OV |
| Module type | Equipotential Output | |
| Number of channels | 16 | |
| Connection type | 1-wire system | |
| Current imitation | <8A | |
| Electrical isolation | No isolation between interface channels,isolated between interfaces and internal bus. | |
