Supports AB orthogonal encoding, pulse + direction, single-phase counting, SSI encoder, etc. as input;
Supports 422 level input and OC input;
Supports 422 level input and OC input;
Each counting channel can be set with filtering, and supports electronic probe and position comparison outpu
T330-N
SiRON
Code: 8517623990
Non-returnable
₹5,000.00
Product Details
Product Description:
Product Description
About selection:
Selection example: T330-N3 represents the bladed I/O module series, with 2-channel
counting input, supporting incremental encoders, pulse direction counting, SSI encoders, and Tama River encoders.
functional Characteristics:
| Code | Function |
| 1 | 2-channel counting input,supporting incremental encoders,pulse direction counting,and SSl encoder |
| 2* | 4-channel counting input,4-channel position comparison output,and support for encoders |
Specifications:
| Power supply parameters | |
| Usys bus input power supply rated woltage | 5V DC+20%115%(4.25V DC~6V DC) |
| Usys bus input power supply rated curent | <50mA(5VDC Time-typical value) |
| Terminal output power supply rated woltage | 5V DC |
| Module anti-power failure difusion | support |
| Connection parameters | |
| Connection technology | PUSH-IN terminal blocks |
| Connection type | System/On-site power supply/input |
| Conductor cnmping area | 26~16AWG/0.2~1.5mm² |
| Strip length | 10mm |
| Installation method | DIN-35 din rail |
| Shell material | PC |
| Environmental conditions | |
| Allowable ambient temperature(during operation) | -40~75℃ |
| Alowable ambient temperature(for storage) | -40~85℃ |
| Protection type | IP20 |
| Pollution grade | 2 |
| Operating altitude | 0~2000m |
| Relative humidity(without condensation) | 5~95%RH |
Function module parameters
| Functional module | |||
| Module type | Counter input (single-phase pulse plus direction, A phase,B phase,AB phase,SSI) | Counting range | 32 position |
| Input method | differential input | Frequency measurement range | 0.04HZ~4Mhz |
| Number of channels | 2 | Counting accuracy | 100ppm |
| Differentialinput voltagelevel | RS422 level (Logic O<200mA;Logic 1>200 mA) | Isolation | yes |
| Maximum input frequency | 4Mhz | nput action display | When the input is in the driving state,the inputindicator lightis on hardware-controlled |
| Single-ended input type | Digital input | Output type | Digital output |
| Input method | single-ended input,NPN/PNP | Output mode | NPN |
| Input channel | 4(The counting channel is 2 channels,with each channel being an AB phase) | Output channel | 2 |
| Frequency measurement range | 0.04Hz~500kHz | Output voltage level | 24V DC+20%115%(20.4V DC~28.8V DC |
| Input voltage level | 24V DC+20%1-15%(20.4V DC~28.8V DC) | Output boad(resistance load) | 0.5A point,1A/module |
| nput current(typical) | 50mA(Typical value of 24V) | Output load(inductance load) | 7.2W/point,1A/module |
| ON voltage | >15VDC | Output boad (light load) | 5W/point,10W/module |
| OFF voltage | <5V DC | Output action display | When the output is in the driving state, the input indicator light is on(hardware-controlled) |
| lsolation status | Yes | Data size | 72 Byte |
| Input action display | When the input is in the driving state,the input indicator light is on(hardware-controlled) | Error diagnosis | Communication diagnosis,configuration parameter diagnosis |
| Communication fault count status mode | Maintain the current count value,reset the count value,and continue counting | Communication fault output status mode | Tum off the output,enable the output, and keep the current output |
| I0 mapping | Supports bit,byte and word mapping modes. | ||
