The coupler supports access via the CANopen protocol;
The coupler supports a maximum input of 128 bytes and a maximum output of 128 bytes;
Up to 16 expansion IO modules can be supported
The coupler supports a maximum input of 128 bytes and a maximum output of 128 bytes;
Up to 16 expansion IO modules can be supported
T330-9
Brand:SiRON
8517799000
Non-returnable
₹5,000.00
Product Details
Product Description:
Product Description
About selection
Model Selection Example: T330-9 is a blade-type I/O module series with CANopen coupler protocol.
Specification
| Power parameters | |
| Terminal input power supply rated vltage | 24VDC(20.4VDC~28.8V DC) |
| Terminal input power supply rated curent | 5A(Typical value at 24V Dc) |
| Usys backplane output power supply rated voltage | 5V DC(4.75V DC~5.25V DC) |
| Usys backplane output power supply rated curent | 2A(Typical value at 5V Dc) |
| Uin backplane output power supply rated voltage | 24VDC(20.4V DC~28.8V DC) |
| Uin backplane output power supply rated curent | 4A(Typical value at 24V Dc) |
| Function parameters | |
| Communication | CANopen |
| Protocol | support 10、20、50、100、125、250、500、1000Kbps |
| Data transmission rate | Configurable via DIP switch,maximum number of slaves supported:12 |
| Bus address setting Transmission distance | The maximum length is 1000 meters,which is actually related to the baud rate and cable impedance |
| Alam function | Standard and Enhanced Diagnostics |
| Isolation method | Electrically isolated from field side |
| Transmission medium | Category 5 twisted pair cable_ |
| Maximum number oflO modules | Support 16 |
| Input PDO data volume | Max 128 Bytes |
| Output PDO data volume | Max 128 Bytes |
| Connection technology:Communication/Fieldbus | CAN 2.0 |
| Connection technology | PUSH-IN terminal block |
| Connection type | System/On-site power supply/input |
| Winding area of the wire | 26~16AWG/0.2~1.5mm² |
| Strip length | 10mm |
| Installation method | DIN-35 |
| Shell material | PC plastic |
| Environmental conditions | |
| Alowable ambient temperature(during operation) | -40~75℃ |
| Allowable ambient temperature(for storage) | -40~85℃ |
| Protection type | IP20 |
| Pollution grade | 2 |
| Operating atitude | 0~2000m |
| Relative humidity(without condensation) | 5~95%RH |
