The coupler supports Modbus/TCP protocol access;
The coupler supports a maximum input/output of 10,000 bytes;
Up to 32 expansion IO modules can be supported.
The coupler supports a maximum input/output of 10,000 bytes;
Up to 32 expansion IO modules can be supported.
T330-6
Brand:SiRON
Code:8517799000
Non-returnable
₹5,000.00
Product Details
Product Description
Product Description
About selection
Model Selection Example: T330-6 represents the blade-type I/O module series with Modbus/TCP coupler protocol.
Specification
| Power parameters | |
| Terminal input power supply rated voltage | 24V DC(20.4VDC~28.8V DC) |
| Terminal input power supply rated current | 5A(Typical value at 24V Dc) |
| Usys backplane output power supply rated voltage | 5V DC(4.75VDC~5.25VDC) |
| Usys backplane output power supply rated current | 2A(Typical value at 5V Dc) |
| Uin backplane output power supply rated voltage | 24V DC(20.4VDC~28.8V DC) |
| Uin backplane output power supply rated current | 4A(Typical value at 24V Dc) |
| Function parameters | ||
| Communication protocol | Modbus/TCP | |
| Communication rate | 10/100Mbps,adaptive,full-duplex | |
| Address mapping | 100 m | |
| Diagnosis | Standard and Enhanced Diagnosis | |
| lsolation method | Electrically isolated from site field circuit | |
| Transmission medium | Cat5 Twisted Pair | |
| IPaddress allocation method | Static IP allocation (configured by software through web pages and hardware dip switches) Support resetting to the default address(192.168.1254) | |
| Minimum cycle time | 502(Modbus TCP standard port) | |
| Connection technology:Communication/Feeback Bus | Configure parameters through the web page | |
| Connection technology | support 7 | |
| Connection type | Max 10000 Bytes | |
| Winding area of the wire | 01/02/03/04/05/06/15/16_ | |
| Striplength | BootLoader mode upgrade,UART serial port interface,YMODEM protocol | |
| Installation method | Modbus/TCP IO:2xRJ-45 | |
| Shell material | PUSH-IN terminal block | |
| Connecion type | System/On-site power supply/input | |
| Winding area ofthe wire | 26~16AWG/0.2~1.5mm² | |
| sripping length | 10mm | |
| Installation method | DIN-35 | |
| Shell material | PC plastic | |
| Environmental conditions | |
| Alowable ambient temperature(during operation) | -40~75℃ |
| Alowable ambient temperature (for storage) | -40~85℃ |
| Protection type | IP20 |
| Pollution grade | 2 |
| Operating altitude | 0~2000m |
| Relative humidity(without condensation) | 5~95%RH |
