The body is made of new aviation aluminum material, which has higher rigidity, lighter quality, simple structure, small occupation space,
and is more suitable for all kinds of installation and collocation.The fastest can reach 5000mm/s.
Long stroke, the longest can achieve 5mm stroke, high repeat positioning accuracy, heavy positioning accuracy can be ±0.01MM
different linear module positioning accuracy to meet different needs,High straightness of operation, the fluctuation value per meter of
straightness processing is less than 0.01MM to ensure smooth and smooth running of the sliding platform, smooth and stable running
of the platform with silver linear sliding rail,The use of P-class linear guide rail and imported NSK bearing, to ensure the linear module
sliding smooth stability, long service life, precision control, impact resistance, cost-effective.
and is more suitable for all kinds of installation and collocation.The fastest can reach 5000mm/s.
Long stroke, the longest can achieve 5mm stroke, high repeat positioning accuracy, heavy positioning accuracy can be ±0.01MM
different linear module positioning accuracy to meet different needs,High straightness of operation, the fluctuation value per meter of
straightness processing is less than 0.01MM to ensure smooth and smooth running of the sliding platform, smooth and stable running
of the platform with silver linear sliding rail,The use of P-class linear guide rail and imported NSK bearing, to ensure the linear module
sliding smooth stability, long service life, precision control, impact resistance, cost-effective.
M364(C)-80
Brand:SiRON
9001909090
Non-returnable
₹5,000.00
Product Details
Product Description
About selection
Model selection example: M364(C)-80-13P-500-BL-T10-E5 is M364(C) series, body code 80, the lead is 13mm Synchronous belt material:polyurethane, the stroke is 500, the left linear module, Delta motor, the power is 100W, No point sensor, no end sensor, no end sensor
Product specification
| Project | Specification | ||||||
| Specifications | Repeatability(mm) | ±0.05 | |||||
| Lead(mm) | 15 | 25 | 50 | 75 | 150 | ||
| Maximum speed(mm/s) | 750 | 1250 | 2000 | 2000 | 2000 | ||
| Maximum payload(kg) | Horizontal | 60 | 45 | 30 | 20 | 10 | |
| Vertical | 一 | 一 | 12 | 8 | 3 | ||
| Reduction Ratio | 1/10 | 1/6 | 1/3 | 1/2 | 1/1 | ||
| Rated thrust(n) | 972 | 583 | 291 | 194 | 98 | ||
| Stroke pitch(mm) | 500~3550mm/50mm | ||||||
| Sarts | AC servo motor capacity (W) | 750 | |||||
| Linear Guide(mm) | W20×H15 | ||||||
| Home sensor | Outside | EE-SX672(NPN)EE-SX672P(PNP) | |||||
Installation method
Suitable motor brand
| Brand | The motor mark | Whether the brakes | Motor capacity | voltage | Motor model | voltage |
| Delta | T | No brakes (horizontal style) | 750 | 220 | ECMA-C20807RS | ASD-B2-0721-B |
| With brake(vertical style) | 750 | 220 | ECMA-C20807SS | ASD-B2-0721-B | ||
Panasonic | P | No brakes(horizontal style) | 750 | 220 | MHMF082L1U2M | MCDLN35SG |
| With brake(vertical style) | 750 | 220 | MHMF082L1V2M | MCDLN35SG | ||
| Yaskawa | Y | No brakes (horizontal style) | 750 | 220 | SGM7J08AFC6S | SGD7S5R5A00A002 |
| With brake(vertical style) | 750 | 220 | SGM7J08AFC6E | SGD7S5R5A00A0022 |
Allowable overhang
Static loading moment
