The fully enclosed linear sliding table module is mainly composed of aluminum body, diagonal bearing fixing seat, cover plate, sliding seat and other components. The linear module adopts corrosion resistance and high strengthThe aluminum alloy material is the base, which is installed with a high-precision linear guide rail pair. The aluminum alloy moving seat is installed on the slider, and the middle of the moving seat is connected with the synchronous belt.The motor drives the sliding block to move reciprocally through the synchronous wheel. The high-precision synchronous wheel and synchronous belt can ensure the repetitive accuracy and positioning accuracy of the moving block, and the flexibility is not rustingThe e steel belt is sealed on the moving seat, the whole can reach the requirements of dust-free grade.
M362-14
Brand:SiRON
Code:9001909090
Non-returnable
₹5,000.00
Product Details
Product Description
About selection
Model selection example: M362-14-5-50-M-M20-A1 is M362 series, the body model is 14, the lead is 5mm, the stroke is 50, the motor is built-in, Mitsubishi motor, the power is 200W, and the built-in motor side of the origin sensor is, A built-in limit sensor.
Product specification
| Project | Specification | |||||
| Specifications | Repeatability(mm) | ±0.005 | ||||
| Ball screw lead(mm) | 5 | 10 | 20 | 32 | ||
| Maximum speed(mm/s) | 250 | 500 | 1000 | 1600 | ||
| Maximum payload(kg) | Horizontal | 95/110 | 75/88 | 35/40 | 15/30 | |
| Vertical | 27/33 | 18/22 | 7/10 | 00/8 | ||
| Rated thrust(n) | 683/1388 | 341/694 | 174/347 | 107/217 | ||
| Stroke pitch(mm) | 5 0 - 1 0 5 0 m m / 5 0 间 隔 | |||||
| Sarts | AC servo motor capacity(W) | 200/400 | ||||
| Outer diameter of ball bearing screw(mm) | C7φ16 | |||||
| High rigidity linear slide rail(mm) | W15×H12.5 | |||||
| Coupling(mm) | 10×14×11/10×14 | |||||
| Home sensor | Outside | K017-A2(NPN) | ||||
| Built-in | EE-SX674(NPN) | |||||
