1.2° step angle, three-phase stepper motor;
High resolution, low noise;
High torque, low vibration, high efficiency;
Precise position control;
It can realize precise control and convenient adjustment.
High resolution, low noise;
High torque, low vibration, high efficiency;
Precise position control;
It can realize precise control and convenient adjustment.
M271-57
Brand:SiRON
Code:8501109990
Non-returnable
Product Details
Product Description
About selection
Selection example: M271-57-0451 represents the M271 series three-phase stepping motor, with a frame size of 57mm, a holding torque of 0.45N.m, and a single axis.
Specification
| Model | M271-57 Series | ||
| Radial Play | 0.02mm@450g | Step Angle | 1.2° |
| Axial Play | 0.08mm@450g | Step Angle Accuracy | ±5%(The entire step is unloaded) |
| Max.radial force | 28N(20mm away from the flange） | Insulation Resistance | 100MΩ,500VDC |
| Max.axial force | 10N | Ambient Temperature | -20℃~+50℃ |
| Dielectric Strength | 900VAC/1s | Insulation Class | Class B |
Electrical properties
| Model | M271-57-0451 | M271-57-0901 | M271-57-1502 |
| Adapter drive | M281-3606 | M281-3606 | M281-3606 |
| Cuent per phase | 5.2 | 5.6 | 5.8 |
| Holding tbrque | 0.45 | 0.9 | 1.5 |
| Positioning torque | 0.021 | 0.04 | 0.068 |
| Each resistance | 1.3 | 0.7 | 1.05 |
| Each inductance | 1.4 | 1.7 | 2.4 |
| Number oflead wires | 6 | 6 | 6 |
| Moment of inertia | 110 | 300 | 480 |
| weight | 0.45 | 0.75 | 1.1 |
| Body length | 42 | 56 | 79 |
