The digital tube displays the channel value and brightness value, which is easy to understand by pressing the key operation;
It can be connected to the computer through the RS232 communication serial port for remote control;
External trigger high and low frequency optional, high-speed optocoupler isolation, fast response, high reliability;
Simple operation, can be adjusted by keys or PC, each channel is individually adjustable, with 256-level precision changes, The brightness of the light source can be precisely controlled.
It can be connected to the computer through the RS232 communication serial port for remote control;
External trigger high and low frequency optional, high-speed optocoupler isolation, fast response, high reliability;
Simple operation, can be adjusted by keys or PC, each channel is individually adjustable, with 256-level precision changes, The brightness of the light source can be precisely controlled.
K791 Series
Brand:SiRON
Code:8479909090
Non-returnable
₹5,000.00
Product Details
Product Description
About selection
Selection example:K791-T2-120 represents the K791 series, with 2 channels and a total output power of 120W.
Note:
For T2/T4 channel models, the total output power can be selected as 60W or 120W.
For T6/T8 channel models, the total output power can be selected as 120W or 200W.
Specifications
Name | Digital controller | |||
Model | K791-T2-60 | K791-T4-60 | K791-T6-120 | K791-T8-120 |
| K791-T2-120 | K791-T4-120 | K791-T6-200 | K791-T8-200 | |
| Appearance |  | |||
The output voltage | Max. 24V DC | |||
External trigger voltage | 5～24V DC | |||
Output Power | 60W/120W | 60W/120W | 120W/200W | 120W/200W |
nput power | 100～200VAC50Hz | |||
Trigger delay time | <50μs | |||
Adjustable brightness level | 0~255 level adjustable | |||
communication method | RS232 | |||
Control state | Switchable between always-on / always-off mode | |||
Ambient temperature | 20～85%RH | |||
Environment humidityn | 0～60℃ | |||
