Constant brightness, uniform chromaticity and long service life;
Developed by using the principle of high-power LEDs to emit parallel light after being focused by an optical lens.
Developed by using the principle of high-power LEDs to emit parallel light after being focused by an optical lens.
Non-returnable
₹5,000.00
Product Details
Product Description
About selection
Selection example: K731-3-R indicates the K731 series, the power is 3W, the light source color is red.
Note: R - red; G - green; B - blue; W - white; IR - infrared; Uv-Ultra Violet.
Secifications
| Name | Highlight light source |
| Appearance |
White Red Green Blue |
| Voltage | 5V |
| Operating temperature | -10～+60℃ |
| Working humidity | 20～85%(No atomization) |
| Controller | Point light source 5V constant current controller |
| Scope of application | Chip detection;Mark point positioning detection; Level glass base alignment |
| Wavelength and color temperature | W:6500K B:465～470nm R:620～630nm IR:850～940nm G:525～530nm UV:365～395nm |
