6 sets of gold-plated contacts; 4 contact combinations;
Locking force 1300N; 11 kinds of operating keys are available;
Indicator + emergency unlock;
Optional front/side emergency unlock.
Locking force 1300N; 11 kinds of operating keys are available;
Indicator + emergency unlock;
Optional front/side emergency unlock.
K090-9-Q4 Series
Brand:SiRON
Code:9031809090
Non-returnable
₹5,000.00
Product Details
Product Description
About selection
Selection Example：K090-9-Q4-A4-R1-H it indicates the K090-9-Q4 series, with mechanical locking/electromagnetic release, built-in switches (3NC + 3NC), resin head material, PG13.5 pipe diameter, and optional emergency unlock knob position at the front.
Specifications
| Series K090 - 9 - Q4 series | ||||
| Solenoid characteristic | ||||
| Rated operating voltage | DC24V±5% | |||
| Rated current | 200mA(initial value) | |||
| Rated power | 4.8W | |||
| Insulation | ClassB(130℃) | |||
| Indicator characteristic | ||||
| LED luminous color | Green | |||
| Rated voltage | DC24V | |||
| Rated current | 1mA | |||
| Peculiarity | ||||
| Life span | Machine | More than one million times | ||
| Electric | More than 150,000 times | |||
| Allowable operating speed | 0.05～0.5m/s | |||
| Allowable operating frequency | Maximum 20 operations per minute | |||
| Forced breaking force | ≥80N | |||
| Force disconnect operating distance | ≥10mm | |||
| Drawing strength at lock | 1300N | |||
| Ratedinsulation voltage(Ui) | 300V | |||
| Rated impulse withstand voltage (Uimp) | 2.5kV | |||
| Category of use | AC-15 | DC-13 | ||
| Rated operating voltage(Ue) | 240V | 30V | 250V | |
| Rated operating current(le) | 3A | 2.3A | 0.27A | |
| Rated limited short circuit current | 1000A | |||
| Rated open thermal current(Ith) | 10A | |||
| Ambient temperature | -20～60℃(No freezing) | |||
| Ambient humidity | Below 85%Rh | |||
| Head mounting direction | Four installation directions are available (default front side) | |||
| Pipe diameter | M20/PG13.5 | |||
| Shell material | PA66 Flame-Retardant | |||
| Contact material | Gold plating of silver alloy | |||
| Class of protection | IP67(except for the key operation hole) | |||
