High brightness LED light source. Improved visibility over long distances.
Built-in noiseless high-decibel buzzer. Obvious warning effect.
Smart signal
D021-B Series
Brand:SiRON
Code:9405410000
Non-returnable
₹5,000.00
Product Details
Product Description
ABOUT SELECTION
|
| ||
| Type analysis | ||
| ① | LED signal lamp series | D021 |
| ② | Non-smart/smart | Blank: Signallight (Z) : USBsmartsignallight |
| ③ | Appearance | B |
| ④ | Light source color (three-colour) | Blank: Red yellow green （RYG） |
| ⑤ | Light source color (single color) | R: red Y: yellow G: green |
| ⑥ | Signal polarity | Blank：NPN P：PNP |
Note: 1. D021(Z)-B lamp source color canonly be selected three colors;
2. D021(Z)-B No signal polarity is optional.
Specifications
| Model number | D021-B | D021(Z)-B |
| Appearance |  | |
| Nominal voltage | 24V DC | 5VDC |
| Rated current | Red light 0.04A,yellow light 0.06A,green light 0.08A | Red light 0.12A,yellow light 0.18A,green light 0.24A |
| Installation method | Bend | Bend |
| Working status | Always on with buzzer | |
| Layer number of color | Three-colour | |
| The material | Lamp shade transparent PC+ lampshell aluminum alloy | |
| Protection grade | IP20 | |
| Bean Angle | 360° | |
| Service life | 50000h | |
| Environment temperature | -25～55℃ | |
| Signal polarity | NPN common positive electrode /PNP common negative electrode | -- |
| Standard wiring length | Standard 1500mm | USB wire length 1000mm |
| Luminescent lampsource color |
Red Yellow Green | |
